Problem Statement
How do you load test a real-time system built on WebSockets (Socket.IO) instead of traditional HTTP APIs?
Standard load-testing approaches often fail because:
- Interactions happen over persistent WebSocket connections
- Users must authenticate, join channels/rooms, and receive real-time events
- Rate limits / cooldown rules restrict how frequently actions can occur
- Correct behavior depends on multiple users interacting with the same resources
- Success is defined by coordination and timing, not just request throughput
We needed to simulate dozens of concurrent users performing thousands of real-time actions in a controlled and realistic way.
What We Tried
Attempt 1: All Users Act at the Same Time
Approach:
Every virtual user (VU) triggered the same action on the same resource simultaneously.
Problem:
Most real-time systems enforce cooldowns or rate limits to prevent spam. When many users act on the same resource within a short window, most actions are rejected.
Result:
High rejection rate and misleading test results.
Attempt 2: Assign Each User a Dedicated Resource
Approach:
Each user interacted with only one unique resource.
Problem:
No real contention. Many systems optimize repeated actions from the same user by updating internal state rather than creating new events.
Result:
Far fewer events than expected; the test didn’t reflect real-world behavior.
Attempt 3: Use sleep() for Delays
Approach:
Insert sleep() calls between actions to respect cooldowns.
Problem:
In k6, sleep() blocks the JavaScript event loop. When used inside WebSocket callbacks, it prevents incoming messages from being processed, leading to dropped connections.
Result:
Connection closures and zero meaningful activity.
What Worked
Distributed Round-Robin Interaction Pattern
Key insight:
At any moment, each user should interact with a different resource, and over time, all users rotate across all resources.
This achieves:
- No rate-limit collisions (different resources at the same time)
- Real competition (same resource receives actions from different users over time)
- Predictable timing and clean metrics
Algorithm
// At step N, user i interacts with resource (i + N) % totalResources
const resourceIndex = (userIndex + stepNumber) % totalResources;
Example: 3 Users × 3 Resources
| Step | User 0 | User 1 | User 2 |
|---|---|---|---|
| 0 | Resource 0 | Resource 1 | Resource 2 |
| 1 | Resource 1 | Resource 2 | Resource 0 |
| 2 | Resource 2 | Resource 0 | Resource 1 |
Each resource receives actions from different users, spaced correctly in time.
Common Pitfalls & Solutions
| Pitfall | Solution |
|---|---|
| High rejection rates | Distribute actions across resources |
| No meaningful contention | Rotate users across shared resources |
| WebSocket disconnects | Avoid sleep() in callbacks |
| Server overload at startup | Stagger connections |
| Early socket closure | Compute keep-alive duration correctly |
| Missing local reports | Use hybrid execution |
Pipeline Integration Tips
- Make load testing optional via pipeline flags
- Run it in parallel with other test stages
- Publish only reports
- Store credentials in secure variables
Results
Using this approach, we were able to simulate:
- Dozens of concurrent WebSocket users
- Thousands of real-time interactions
- Sustained load over extended durations
- Consistently high success rates
Key Learnings
- WebSocket testing requires event-driven thinking
- Domain constraints shape your test strategy
- Staggering avoids the thundering herd problem
- Round-robin patterns create realistic contention
- k6 supports powerful real-time testing when used correctly
Reusable For
This pattern applies to any real-time, multi-user system, such as:
- Live collaboration tools
- Multiplayer or matchmaking systems
- Real-time dashboards
- Messaging platforms with rate limits
- Event-driven backends
